適用外胎種類 Applicable types of tyres | 摩托車輪胎 Mobike tyres | 摩托車輪胎 Mobike tyres |
規(guī)格 Specification | 8″-21″ | 4″-12″ |
模型數(shù)量 No. of molds | 2-4 | 2-4 |
總壓力（每個模型） Total pressure (each mold) (Mpa) | 100 | 60 |
液壓系統(tǒng)壓力設定值 Hydraulic system pressure setting (Mpa) | ≤21 | ≤21 |
液壓工作壓力設定值 Hydraulic working pressure setting (Mpa) | ≤19.5 | ≤19.5 |
熱板直徑 Dia. of hot plate (mm) | 950 | 650 |
保溫罩內徑 Inner dia. of insulation cover (mm) | Φ975 | Φ700 |
最大熱板間距 Max. clearance between plates (mm) | 1000 | 1000 |
適用模具高度 Applicable mold height (mm) | 120-300 | 120-300 |
生胎最大厚度 Max. thickness of green tyre (mm) | 450 | 450 |
脫模力 Demolding force (k) | 750 | 750 |
最大頂胎高度 Max. height of the top tire (mm) | 200 | 200 |
開（合）模速度 Open (close) mold speed (mm/s) | 60 | 60 |
熱板加熱蒸汽壓力 Hot plate heating steam pressure (Mpa) | Max.1.0 | Max.1.0 |
內壓蒸汽或壓縮空氣壓力 Inner pressure steam or compressed air pressure (Mpa) | 1.5-2.3 | 1.5-2.3 |
定型蒸汽或壓縮空氣壓力 Shaping steam or compressed air pressure (Mpa) | 0.1-0.2 | 0.1-0.2 |
水（氣）缸用壓力 Water (gas) cylinder use pressure (Mpa) | 1.5-2 | 1.5-2 |
控制用壓縮空氣壓力 Controlling use compressed air pressure (Mpa) | 0.35 | 0.35 |
真空度 Vacuum (Mpa) | 0.013-0.026 | 0.013-0.026 |
液壓油 Hydraulic oil | 46#anti-wear hydraulic oil | 46#anti-wear hydraulic oil |
油泵電機 Pump motor (kw) | Y180L-4-22 | Y180L-4-22 |
機器總重量 Total weight (kg) | 11500 | 9500 |
